ABB Miniature Circuit Breaker C Curve 80Amp 6 kA 1 Number of Poles Module 52.5mm DIN Rail Mount

chevron-left
loader
Loading...

Description

chevron-down
Miniature Circuit Breaker C Curve, 230-400 Volt, 80 Amp, 50/60 Hz, 6 kA Interrupt Capacity, 1 Module, 1 Pole, Toggle Actuator, 3 Nm Tightening Torque, Screw Terminal, 10000 Cycles Electrical Life, IP20, DIN Rail Mounting, Light Grey, 25 to 55 deg C, 88 mm Height, 17.5 mm Width, 69 mm Depth

Key Specifications

chevron-down
SKU
ABBS201C80
Brand
ABB
Product Type
Mini Circuit Breakers

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Standard Pack Size 1
UNSPSC Class 39121600
UOM EA
Vendor Product S201C80
Actuator Type Toggle
Colour Light Grey
Current 80 Amp
Depth 69 mm
Electrical Life 10000 Cycles
Frequency 50/60 Hz
Height 88 mm
Interrupt Capacity 6 kA
IP Rating IP20
Modules 1 Module
Mounting Method DIN Rail
Number Of Poles 1 Pole
Temperature 25 to 55 deg C
Terminal Type Screw
Tightening Torque 3 Nm
Voltage 230-400 Volt
Width 17.5 mm
