B&R Meter Box New South Wale 12 Pole W600mm H600mm D270mm DIN Mount Steel Galvanised Black

Description

Meter Box New South Wales, 12 Pole, Top Hinged Door, 600 mm Enclosure Height, 600 mm Enclosure Width, 270 mm Enclosure Depth, 560 mm Panel Height, 575 mm Panel Width, IP23, DIN Rail Mounting, Steel, Black, Galvanised

Key Specifications

SKU	B&RNSW/BP/GD10
Brand	B&R
Product Type	Meter Boxes Domestic

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Designed for both single and multi-phase installations Suitable for domestic and light commercial metering applications Provides versatility with a large range of products and accessories Entry level range of enclosures Top hinged with panel DIN panel cut-out Earth and neutral links NOT included Manufactured from 1.0mm or 1.2mm galvanised steel to Z275
Standard Pack Size	1
UNSPSC Class	39121100
UOM	EA
Vendor Product	NSW/BP/GD10
Colour	Black
Door Type	Top Hinged
Enclosure Depth	270 mm
Enclosure Height	600 mm
Enclosure Width	600 mm
Finish	Galvanised
Material	Steel
IP Rating	IP23
Mounting Method	DIN Rail
Number Of Poles	12 Pole
Panel Height	560 mm
Panel Width	575 mm
