Contactor GP DC Operated 3P 7.5kW 9A AC3 25A AC1 24VDC 1NOi

Lovato Contactor General Purpose DC Operated 3 Pole 7.5kW 9A AC3 25A AC1 24VDC 1NO Auxiliary DIN Rail/Base Mount

PRODUCT CODE:
LOVBF0910D024

Std Pack Size
1
OUR P/N:
LOVBF0910D024

You need to be registered and logged in to view product details and pricing

Contactor General Purpose DC Operated, 24 Volt DC, AC3 Rating (kW): 7.5 at 55 deg C, AC3 Rating (Amps): 9, AC1 Rating (Amps): 25, 690 Volt, 1NO Auxiliary, 3 Pole, Screw Terminal, DIN Rail/Base Mount, IP20, -50 to 70 deg C, 126 mm Height, 45 mm Width, 98.5 mm Depth

Additional Information

Additional Information
Brand Lovato
Range Name Orange BF
Standard Pack Size 1
UNSPSC Class 39121500
UOM EA
Vendor Product LOVBF0910D024
AC1 Rating (Amps) 25 Amp AC1
AC3 Rating (Amps) 9 Amp AC3
AC3 Rating (kW) 7.5 kW
Contact Configuration 1 Normally Opened Aux
Contact Voltage 690 Volt
Height 126 mm
IP Rating IP20
Depth 98.5 mm
Number Of Poles 3 Pole
Mounting Method DIN Rail/Base
Operating Coil Voltage 24 Volt DC
Temperature -50 to 70 deg C
Product Type Contactors General
Width 45 mm
Terminal Connection Screw
