Contactor GP AC Operated 3P 10kW 12A AC3 28A AC1 415V 1NC

Lovato Contactor General Purpose AC Operated 3 Pole 10kW 12A AC3 28A AC1 415V 1NC Auxilary DIN Rail/Base Mount

PRODUCT CODE:
LOVBF1201A415

Std Pack Size
1
OUR P/N:
LOVBF1201A415

You need to be registered and logged in to view product details and pricing

Contactor General Purpose AC Operated, 415 Volt AC, AC3 Rating (kW): 10 at 55 deg C, AC3 Rating (Amps): 12, AC1 Rating (Amps): 28, 690 Volt, 1NC Auxiliary, 3 Pole, Screw Terminal, DIN Rail/Base Mount, IP20, -50 to 70 deg C, 126 mm Height, 45 mm Width, 80.7 mm Depth

Additional Information

Additional Information
Brand Lovato
Range Name Orange BF
Standard Pack Size 1
UNSPSC Class 39121500
UOM EA
Vendor Product LOVBF1201A415
AC1 Rating (Amps) 28 Amp AC1
AC3 Rating (Amps) 12 Amp AC3
AC3 Rating (kW) 10 kW
Contact Configuration 1 Normally Closed Aux
Contact Voltage 690 Volt
Height 126 mm
IP Rating IP20
Depth 80.7 mm
Number Of Poles 3 Pole
Mounting Method DIN Rail/Base
Operating Coil Voltage 415 Volt AC
Temperature -50 to 70 deg C
Product Type Contactors General
Width 45 mm
Terminal Connection Screw
