Panduit Pan-Net Cable Cat6A U/UTP 4 Pair 23 AWG Copper Vari-MaTriX HDPE/LSZH Blue 305m

$Panduit\Panduit_PUL6AHD04BU-EG.JPG$

Description

CAT 6A/Class EA cable shall be constructed of 23 AWG copper conductors with Foam PE and HDPE (CM and CMR) or HDPE Low Smoke Zero Halogen (LSZH), insulation. The copper conductors shall be twisted in pairs and separated by a tape style divider. All four pairs shall be surrounded by a metallic VariMaTriX tape and a flame retardant jacket. The Vari-MaTriX tape shall minimize the cable diameter and suppress the effects of alien crosstalk while retaining UTP electromagnetic interference immunity. The small cable diameter shall maximize cable density such that existing pathways can be utilized when upgrading from CAT 6 cabling.

Key Specifications

SKU	PADPUL6AHD04BU-EG
Brand	Panduit

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Vari-MaTriX HD Technology: Best-in-class cable diameter delivers superior PSANEXT and PSAACRF suppression while retaining UTP EMI immunity Superior headroom warranty: Provides the highest worst-case margins above the industry standard for both electrical and alien crosstalk performance High density cable design: Improves fill capacity, cable management, reduces required bend radius and allows efficient use of pathways and spaces Extended temperature range: Allows operation in 75 deg C (167 deg F) ambient environment providing error free performance in high-density cabinets and large cable bundles running PoE+ or PoE++ applications Highest density: All testing and headroom based on 48-port/1 RU panels Descending length cable markings: Easy identification of remaining cable reduces installation time and cable scrap
Standard Pack Size	1
UNSPSC Class	26121600
UOM	RO
Vendor Product	PUL6AHD04BU-EG
Conductor Material	Bare copper
Cable Type	Cat 6A
Bend Radius	24.8 mm
Conductor Size	23 AWG
Conductor Type	Copper
Insulation Material	HDPE
Max. Pulling Force	110 N
Outside Diameter	6.2 mm
Pair Count	4 Pair
Sheath Colour	Blue
Sheath Material	LSZH
Shielded Type	U/UTP
Temperature	20 to 75 deg C
Voltage	80 Volt
