Panduit Narrow Forked Spade Insulated Double Grip 1.5-2.5mm M5 Stud Blue 21.1mm OAL

Description

Narrow Forked Spade Terminal, Insulated, Double Grip, Conductor Size: 1.5-2.5 mm, Stud Size: M5, Terminal Type: Standard, 600 Volt Maximum, Wire Strip Length: 7.1mm, Barrel Type: Butted, Seam Type: Butted, Crimping Die: KST2000A, Mounting Method: Free Hanging, Body Material: Copper, Conductive Material: Copper, Insulation Material: Vinyl, Blue Insulation, Tin Plated Finish, 221 deg F, 21.1mm Overall Length, 11.2mm Lug Length, 7.9mm Lug Width, 0.8mm Lug Thickness, 5.31mm Lug Inside Width, Barrel Length: 9.9mm, Max. Insulation Diameter: 4.2mm, 25 Pack

Key Specifications

SKU	PANEV14-10FNB-Q
Brand	Panduit
Range Name	StrongHold
Product Type	Forked & Ring Terminals

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	25
UNSPSC Class	39121400
UOM	EA
Vendor Product	EV14-10FNB-Q
Barrel Length	9.9 mm
Barrel Type	Butted
Conductive Material	Copper
Body Material	Copper
Conductor Size	1.5-2.5mm
Crimping Die	KST2000A
Finish	Tin Plated
Insulation Diameter	4.2 mm
Insulation Colour	Blue
Insulation Material	Vinyl
Lug Inside Width	5.31 mm
Lug Length	11.2 mm
Lug Thickness	0.8 mm
Lug Width	7.9 mm
Pack Size	25 Pack
Mounting Method	Free Hanging
Overall Length	21.1 mm
Seam Type	Butted
Stud Size	M5 Stud
Temperature	221 deg F
Terminal Type	Standard
Voltage Rating	600 Volt
Wire Strip Length	7.1 mm
