Forked Spade Insulated SGrip 1.5-2.5mm M4 Stud Blue

Product Code
PANEV14-8LFB-L
Std Pack Size
50

You need to be registered and logged in to view product details and pricing

Description

Locking Forked Spade Terminal, Insulated, Single Grip, 1.5-2.5 mm Conductor, M4 Stud, Spring Snap Terminal, 600 Volt Maximum, Wire Strip Length: 7.9 mm, Bevelled Serrated Barrel, Butted Seam, Free Hanging, Copper Body, Copper Conductor, Vinyl Insulation, Blue Insulation, Tin Plated Finish, 221 deg F, 24.6 mm Overall Length, 12.3 mm Lug Length, 7.4 mm Lug Width, 0.8 mm Lug Thickness, 4.06 mm Lug Inside Width, Barrel Length: 12.3 mm, Max. Insulation Diameter: 4.3 mm, 50 Pack
Locking Forked Spade Terminal, Insulated, Single Grip, 1.5-2.5 mm Conductor, M4 Stud, Spring Snap Terminal, 600 Volt Maximum, Wire Strip Length: 7.9 mm, Bevelled Serrated Barrel, Butted Seam, Free Hanging, Copper Body, Copper Conductor, Vinyl Insulation, Blue Insulation, Tin Plated Finish, 221 deg F, 24.6 mm Overall Length, 12.3 mm Lug Length, 7.4 mm Lug Width, 0.8 mm Lug Thickness, 4.06 mm Lug Inside Width, Barrel Length: 12.3 mm, Max. Insulation Diameter: 4.3 mm, 50 Pack

Additional Information

Additional Information
Brand Panduit
Range Name StrongHold
Standard Pack Size 50
UNSPSC Class 39121400
UOM EA
Vendor Product EV14-8LFB-L
Voltage Rating 600 Volt
Body Material Copper
Barrel Length 12.3mm
Barrel Type Bevelled Serrated
Lug Width 7.4mm
Conductor Size 1.5-2.5mm
Conductive Material Copper
Wire Strip Length 7.9 mm
Finish Tin Plated
Lug Thickness 0.8mm
Insulation Colour Blue
Insulation Material Vinyl
Lug Length 12.3mm
Pack Size 50 Pack
Insulation Diameter 4.3mm
Product Type Forked & Ring Terminals
Seam Type Butted
Overall Length 24.6mm
Mounting Method Free Hanging
Terminal Type Spring Snap
Temperature 221 deg F
Stud Size M4 Stud
Lug Inside Width 4.06mm
