Panduit Ring Terminal Insulated Double Grip 1.5-2.5mm M5 Stud Blue 25.7mm OAL

Description

Ring Terminal, Insulated, Double Grip, Conductor Size: 1.5-2.5 mm, Stud Size: M5, Terminal Type: Circular, 600 Volt Maximum, Wire Strip Length: 7.9mm, Barrel Type: Funnel, Serrated, Seam Type: Butted, Crimping Die: CT-1550, CT-2500, Mounting Method: Free Hanging, Body Material: Copper, Conductive Material: Copper, Insulation Material: Vinyl, Blue Insulation, Tin Plated Finish, 221 deg F, 25.7mm Overall Length, 11.9mm Lug Length, 8.9mm Lug Width, 20.6mm Lug Thickness, 5.3mm Lug Inside Diameter, Barrel Length: 11.9mm, Max. Insulation Diameter: 4.3mm, 100 Pack

Key Specifications

Barcode (EAN-13)	7498384234
SKU	PANPMV2-5RB-C
Brand	Panduit
Range Name	Pan-Term PMV-R
Product Type	Forked & Ring Terminals

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Ring tongue design assures a secure connection in high vibration applications Insulation support helps to prevent wire damage in bending applications Brazed seam protects terminal barrel from splitting during the crimp process Internal barrel serrations assure good wire contact and maximum tensile strength
Standard Pack Size	100
UNSPSC Class	39121400
UOM	EA
Vendor Product	PMV2-5RB-C
Barrel Length	11.9 mm
Barrel Type	Funnel/Serrated
Conductive Material	Copper
Body Material	Copper
Conductor Size	1.5-2.5mm
Crimping Die	CT-1550/CT-2500
Finish	Tin Plated
Insulation Diameter	4.3 mm
Insulation Colour	Blue
Lug Inside Diameter	5.3 mm
Insulation Material	Vinyl
Lug Length	11.9 mm
Lug Thickness	20.6 mm
Lug Width	8.9 mm
Pack Size	100 Pack
Mounting Method	Free Hanging
Overall Length	25.7 mm
Seam Type	Butted
Stud Size	M5 Stud
Temperature	221 deg F
Terminal Type	Circular
Voltage Rating	600 Volt
Wire Strip Length	7.9 mm
