Schneider Contactor General Purpose DC Operated 3 Pole 5.5kW 12A AC3 25A AC1 125VDC 1NO-1NC Aux DIN Rail/Plate Mount

Description

Contactor General Purpose DC Operated, 125 Volt DC, AC3 Rating (kW): 5.5, AC3 Rating (Amps): 12 at 440 Volt AC, AC1 Rating (Amps): 25 at 440 Volt AC, 690 Volt AC, 300 Volt DC, 1NO-1NC Auxiliary, 3 Pole, Operating Time: 53.55-72.45 ms Closing, 16-24 ms Opening, Screw Clamp, DIN Rail/Plate Mount, IP20, -40 to 60 deg C, 77 mm Height, 45 mm Width, 95 mm Depth

Key Specifications

Barcode (EAN-13)	3389110353938
SKU	TEELC1-D12GD
Brand	Schneider
Range Name	TeSys Model D
Product Type	Contactors General

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39121500
UOM	EA
Vendor Product	LC1D12GD
AC1 Rating (Amps)	25 Amp AC1
AC3 Rating (Amps)	12 Amp AC3
AC3 Rating (kW)	5.5 kW
Contact Configuration	1 Normally Opened & 1 Normally Closed Aux
Contact Voltage	690 Volt AC/300 Volt DC
Depth	95 mm
Height	77 mm
IP Rating	IP20
Mounting Method	DIN Rail/Plate
Number Of Poles	3 Pole
Operating Coil Voltage	125 Volt DC
Operating Time	53.55-72.45 ms Closing/16-24 ms Opening
Temperature	-40 to 60 deg C
Terminal Connection	Screw Clamp
Width	45 mm
