ABB Miniature Circuit Breaker C Curve 80Amp 6 kA 3 Number of Poles Module 52.5mm DIN Rail Mount
Loading...
Description
Miniature Circuit Breaker C Curve, 400-440 Volt, 80 Amp, 50/60 Hz, 6 kA Interrupt Capacity, 3 Module, 3 Pole, Toggle Actuator, 3 Nm Tightening Torque, Screw Terminal, 10000 Cycles Electrical Life, IP20, DIN Rail Mounting, Light Grey, 25 to 55 deg C, 88 mm Height, 52.5 mm Width, 69 mm Depth
Key Specifications
| SKU |
ABBS203C80
|
|---|---|
| Brand |
ABB
|
| Product Type |
Mini Circuit Breakers
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | S203C80 |
| Actuator Type | Toggle |
| Colour | Light Grey |
| Current | 80 Amp |
| Depth | 69 mm |
| Electrical Life | 10000 Cycles |
| Frequency | 50/60 Hz |
| Height | 88 mm |
| Interrupt Capacity | 6 kA |
| IP Rating | IP20 |
| Modules | 3 Module |
| Mounting Method | DIN Rail |
| Number Of Poles | 3 Pole |
| Temperature | 25 to 55 deg C |
| Terminal Type | Screw |
| Tightening Torque | 3 Nm |
| Voltage | 400-440 Volt |
| Width | 52.5 mm |
