Bussmann Fuse Link HRC Clip In Offset 6 Amp 415 Volt AC 80 kA Class gG BS88 Type A1
Loading...
Description
Fuse Link HRC Clip In Offset, 415 Volt AC, 6 Amp, Class gG, Interrupt Capacity: 80 kA, 58.5mm Fixing Centres, Clip In Offset Tag, 14mm Diameter x 60mm Length, BS88 Type A1
Key Specifications
| SKU |
BUSNS6
|
|---|---|
| Brand |
Bussmann
|
| Product Type |
Fuse Links HRC Clip In
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Features |
|
|---|---|
| Standard Pack Size | 1 |
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | NS6 |
| Current | 6 Amp |
| Dimensions | 14 mm Diameter x 60 mm Length |
| Fixing Centres | 58.5 mm |
| Interrupt Capacity | 80 kA |
| Tag Type | Clip In Offset |
| Standard Reference | BS88 Type A1 |
| Voltage | 415 Volt AC |
| Utilisation Category | Class gG |
