Elcon 4mm 3 Core Grey Flexible Cable Heavy Duty V-90HT PVC/5V-90 PVC

Description

Flexible Cable, Heavy Duty, 4 mm, Annealed Copper, 0.6-1 kV, 25 Amp, 3 Core, 56/0.3 mm Strands, 13.4 mm Overall Diameter, 1 mm Insulation Thickness, 2 mm Sheath Thickness, DC:4.95 Ohm/km Insulation Resistance, V-90HT PVC Insulation, 5V-90 PVC Sheath, Grey Sheath, AS/NZS 1125

Key Specifications

SKU	ELNELMH3040S100M
Brand	Elcon Cables
Product Type	Flexible Cable Heavy Duty

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	100
UNSPSC Class	26121600
UOM	MTR
Vendor Product	ELMH3040S100M
Conductor Size	4 mm
Conductor Type	Annealed Copper
Current	25 Amp
Insulation Material	V-90HT PVC
Insulation Resistance	DC:4.95 Ohm/km
Insulation Thickness	1 mm
Number of Cores	3 Core
Overall Diameter	13.4 mm
Sheath Colour	Grey
Sheath Material	5V-90 PVC
Sheath Thickness	2 mm
Standards	AS/NZS 1125
Stranding	56/0.3 mm
Voltage	0.6-1 kV
