Panduit TX6 U/UTP Data Cable Cat6 4 Pair 23AWG Polyolefin/Polyethylene Black 305M

$Panduit\Panduit_PUO6C04BL-CEG.jpg$

Description

CAT 6 OSP cable shall meet the ANSI/TIA-568.2-D and IEC 61156-5 CAT 6 component Standards. The conductors shall be 23 AWG construction with polyolefin insulation. The cable shall have a gel-filled construction to prevent moisture migration in underground and wet applications and a wide temperature range for extreme weather environments. The copper conductors shall be twisted in pairs, separated by a pair separator and covered with a UV-resistant and abrasion-resistant polyethylene (PE) jacket. Product is to be used in duct and conduit installations only. Not to be used in aerial or direct burial applications.

Key Specifications

SKU	PADPUO6C04BL-CEG
Brand	Panduit

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Robust design: Protects against environmental elements that can cause electrical performance failures Flooding compound: Waterproof gel prevents moisture migration Reel: Ensures proper performance and provides quick installation Descending length cable markings: Easy identification of remaining cable reduces installation time and cable scrap
Standard Pack Size	1
UNSPSC Class	26121600
UOM	RL
Vendor Product	PUO6C04BL-CEG
Bend Radius	26 mm
Cable Type	Cat 6 U/UTP Outside Plant (OSP)
Conductor Material	Bare copper
Conductor Size	23 AWG
Conductor Type	Solid
Frequency Bandwidth	250 MHz
Insulation Material	Polyolefin
Max. Pulling Force	110 N
Outside Diameter	6.7 mm
Pair Count	4 Pair
Sheath Material	HDPE
Sheath Colour	Black
Temperature	40 to 80 deg C
Voltage	80 Volt
