ABB Auxiliary Contact Block Front Mount 1 Pole 2/3/4/6A 24-690V 4NC IP20 Screw

chevron-left
loader
Loading...

Description

chevron-down
Auxiliary Contact Block Front Mount, 2/3/4/6 Amp, 24-690 Volt AC, 4 NC, 1 Pole, Front Mount, Screw Terminal, IP20, 43 mm Height, 43 mm Width, 39.5 mm Depth, For Use With: AF09, AF12, AF16, AF26, AF30, AF38, AF40, AF52, NF Contactors

Key Specifications

chevron-down
Barcode (EAN-13)
3471523130159
SKU
ABBCA404E
Brand
ABB
Product Type
Contactor Auxiliaries

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • The auxiliary contact blocks are used for the operation of auxiliary circuits and control circuits for standard industrial environments
  • CAL4 2-pole block, with instantaneous N.O. + N.C. contacts
  • For clipping onto the right- and/or left-hand side of the contactors
  • The auxiliary contact blocks are equipped with screw type connecting terminals delivered open, protected against accidental direct contact and bear the corresponding function marking
Standard Pack Size 1
UNSPSC Class 39121500
UOM EA
Vendor Product CA404E
Contact Configuration 4 Normally Closed
Depth 39.5 mm
For Use With AF09 AF12 AF16 AF26 AF30 AF38 AF40 AF52 NF Contactors
Height 43 mm
IP Rating IP20
Number Of Poles 1 Pole
Mounting Method Front
Operational Voltage 24-690 Volt AC
Operational Current 2/3/4/6 Amp
Terminal Connection Screw
Width 43 mm
