Electra Variable Speed Drive Cable 2 Core + Earth 0.6/1kV Copper Shielded Copper Braid Screened PVC/PVC Clear Sheath

Description

VSD Cable, 2.4 mm, Class 5 Annealed Copper, 0.6-1 kV, 2 Core + Earth, 12.5 mm Overall Diameter, 0.8 mm Insulation Thickness, 1.8 mm Sheath Thickness, Tinned Copper Braid Screen, V-90HT PVC Insulation, PVC Sheath, Clear Sheath, AS/NZS 1125 AS/NZS 3808 AS/NZS 5000.1

Key Specifications

SKU	ELCVSD2025E-CLEAR
Brand	Electra
Product Type	VSD Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	26121600
UOM	MTR
Vendor Product	VSD2025E CLEAR
Conductor Size	2.4 mm
Conductor Type	Class 5 Annealed Copper
Insulation Material	V-90HT PVC
Insulation Thickness	0.8 mm
Number of Cores	2 Core + Earth
Overall Diameter	12.5 mm
Screen Material	Tinned Copper Braid
Sheath Colour	Clear
Sheath Material	PVC
Sheath Thickness	1.8 mm
Standards	AS/NZS 1125 AS/NZS 3808 AS/NZS 5000.1
Voltage	0.6-1 kV
