Finder Miniature Relay Plug In Or Faston Connection 2P 2CO 8A 240V 8 Pin Flat

Description

Miniature Relay, 250 Volt AC, 240 Volt AC Coil Voltage, 8 Amp, 0.37 kW, 8 Pin Flat, 2 Pole, 2 Changeover Configuration, 31500 Ohm, 3 ms Breaking/10 ms making Operating Time, 100000 Cycles, Plug-In/Faston Connection Mounting, Silver Nickel (Ag/Ni) Contact, -40 to 70 deg C, 32.8 mm Height, 29 mm Width, 12.4 mm Depth, With PB plus/LED plus/Mechanical Indicator

Key Specifications

Barcode (EAN-13)	8012823305806
SKU	FID46.52.0054240VAC
Brand	Finder
Range Name	Series 46

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Complete range from PCB to power relays to cover all of your switching requirements Compact construction allowing for most efficient use of space
Standard Pack Size	1
UNSPSC Class	39122300
UOM	EA
Vendor Product	46520054240VAC
Contact Material	Silver Nickel (Ag/Ni)
Current	8 Amp
Contact Configuration	2 Changeover
Mounting Method	Plug-In/Faston Connection
Depth	12.4 mm
Height	32.8 mm
Number Of Poles	2 Pole
Operating Coil Voltage	240 Volt AC
Operating Cycles	100000 Cycles
Operating Time	3 ms Breaking/10 ms making
Pin Configuration	8 Pin Flat
Power Rating	0.37 kW
Please Note	With PB plus/LED plus/Mechanical Indicator
Temperature	-40 to 70 deg C
Resistance	31500 Ohm
Voltage	250 Volt AC
Width	29 mm
