Legrand Residual Current Breaker with Overcurrent Protection (RCBO) 20Amp 10kA 30mA B Curve 1 Pole 1 Module

chevron-left
loader
Loading...

Description

chevron-down
Legrand Residual current Circuit Breaker with Overload (RCBO) and positive contact indication for control with solid neutral lead that fit perfectly our distribution boards. Ideal for commercial application when chassis (fishbone type) are used with distribution boards. Gives protection against short circuits and overloads, and isolation of electrical circuits. It protects people from direct and indirect contact and protecting installations from insulation faults. There are 2 poles including 1 protected pole and 1 neutral pole.

Key Specifications

chevron-down
Barcode (EAN-13)
341497102353
SKU
LEG418935
Brand
Legrand

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Standard Pack Size 1
UNSPSC Class 39121600
UOM EA
Vendor Product 418935
Colour Black
Current 20 Amp
Height 97 mm
Depth 17.7 mm
Modules 1 Module
Frequency 50/60 Hz
Interrupt Capacity 10 kA
Mounting Method DIN Rail
IP Rating IP20
Number Of Poles 1 Pole
Temperature 25 to 70 deg C
Trip Characteristic B Curve
Trip Sensitivity 30 mA
Voltage 240 Volt
Width 74.4 mm
