Braemar Air Conditioner Split System Inverter 8kW Cool 8.4kW Heat 40-51dBA Indoor/59dBA Outdoor 2.46kW Cool/2.55kW Heat

Description

Air Conditioner, Cooling Capacity: 8 kW, Heating Capacity: 8.4 kW, Rated Current (Cooling): 16 Amp, Rated Current (Heating): 16 Amp, Cooling Air Flow Rate: 250-333 l/sec, Heating Air Flow Rate: 250-333 l/sec, Refrigerant Type: R410A, 40-51 dBA Indoor/59 dBA Outdoor, 220-240 Volt AC, 1 Phase , 50 Hz, 2.46 kW Cooling/2.55 kW Heating, Indoor 326mm Height x 1178mm Width x 253mm Depth, Outdoor 790mm Height x 980mm Width x 427mm Depth, 18-43 deg C Cooling/-7 to 24 deg C Heating, Set temperature range:16 to 30 deg C

Key Specifications

Barcode (EAN-13)	09312168003627
SKU	SEYBCHV80D1S
Brand	Braemar
Range Name	Universal Series
Product Type	Air Conditioning

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	DRED (RJ45 connector Saves power in peak usage times, refer to page 5 for more information Long pipe runs (up to 30m) Allows more flexibility in placing an Outdoor unit DC fan motor and DC compressor Saves you money by reducing running costs Slim design Allows more flexibility in placing an Outdoor unit Single drain connection point Allows faster installation Wide Outdoor operating range 5 fan settings:Select the most comfortable setting for improved personal comfort I Feel wireless remote control Motorised vertical louvers, up-down airflow Auto restart
Standard Pack Size	1
UNSPSC Class	40101700
UOM	EA
Vendor Product	BCHV80D1S
Cooling Capacity	8 kW
Cooling Air Flow Rate	250-333 l/sec
Heating Air Flow Rate	250-333 l/sec
Heating Capacity	8.4 kW
Indoor Dimensions	326 mm Height x 1178 mm Width x 253 mm Depth
Outdoor Dimensions	790 mm Height x 980 mm Width x 427 mm Depth
Power Supply	220-240 Volt AC 1 Phase 50 Hz/2.46 kW Cooling/2.55 kW Heating
Please Note	Set temperature range:16 to 30 deg C
Rated Current (Cooling)	16 Amp
Rated Current (Heating)	16 Amp
Sound Level	40/51 dBA Indoor 59 dBA Outdoor
Refrigerant Type	R410A
Temperature	18-43 deg C Cooling/-7 to 24 deg C Heating
